One antenna, one dish, one headend — clean TV signal to every room in the building, instead of a forest of individual dishes on the roof.
The focused diagram shows only the system nodes covered by this page. Read the highlighted path, role and scope condition to understand what is included and what needs separate confirmation.
Defines the shared infrastructure and separate service boundaries for network, WiFi, SIP telephony and TV media distribution.
This page covers: SMATV and MATV form the television distribution path, with headend, cabling and outlet quantities confirmed separately.
Open component 06 in the complete Solution →MATV (Master Antenna TV) distributes terrestrial channels from one rooftop antenna to every room over coaxial cabling. SMATV (Satellite MATV) adds satellite reception — one dish and headend serving the whole building, including centralised Astro distribution — so a hotel or apartment doesn't need a separate dish and decoder chaos for every unit.
Satellite dish and/or terrestrial antenna, positioned and aligned for stable signal — including Astro centralised reception.
The equipment room where signals are processed, combined and amplified before distribution — the heart of the system, designed per building size.
Amplifiers, splitters and tap-offs calculated floor by floor so signal strength stays correct at every outlet — not strong on level 2 and unwatchable on level 8.
SMATV/MATV distributes TV over coaxial cabling; IPTV delivers it over network cabling with centralised content management and custom welcome screens. Older buildings with existing coaxial often stay on SMATV; new builds may go straight to IPTV; some hotels run both — SMATV for broadcast channels, IPTV for the interactive layer. We'll recommend based on your building's cabling and what you actually need, not push the more expensive option.
SMATV at Podium and Miri Jinhole Hotel; apartment stack at Fulton Park.
Book a site survey — we'll assess your building's cabling and design the distribution properly.
