Essential Pro
Everyday monitoring with infrared night vision and PoE network cameras.
Explore models
Conceptual system scene · not a site photograph
PoE Cameras · NVR · Pro SeriesIP CCTV Pro
IP CCTV Pro
Networked protection
Compare four PoE camera and NVR workflows, from infrared monitoring to two-way talk and active deterrence. Add panoramic coverage only where it suits the viewing requirement.
Choose the workflow you need
Compare the purpose of each plan, then confirm the exact devices and installation scope.
Interactive Pro
Smart Hybrid Light, audio pick-up and human / vehicle detection.
Explore modelsProactive Pro
Two-way talk with camera strobe and siren response.
Explore modelsProactive Defence Pro
Proactive cameras with an AX HYBRID PRO alarm-panel workflow.
Explore modelsInteractive Pro specifies a built-in microphone, not two-way talk. Proactive Pro adds a speaker, strobe and siren. Exact resolution, recording and response settings depend on the selected model.
Models matched to the job
Compare the exact model, not only the series name.
These are related model options. HJ confirms the final configuration and compatibility.
Quick searches match reference text within your selected plan. HJ confirms the exact configuration and compatibility.
47 model references
Indoor turret
DS-2CD1323G0E-IEssential Pro
2MP 1080p · 2.8 mm · EXIR 2.0 30 m IR night vision · H.265+ · PoE · IP67 turret
Outdoor bullet
DS-2CD1023G0E-IEssential Pro
2MP 1080p · 2.8 mm · EXIR 2.0 30 m IR night vision · H.265+ · PoE · IP67 bullet
Indoor turret
DS-2CD1343G0-I(UF)Essential Pro
4MP 2560x1440 · 2.8 mm · EXIR 2.0 30 m IR · 120 dB WDR · H.265+ · PoE · IP67 turret
Outdoor bullet
DS-2CD1043G2-I(UF)Essential Pro
4MP 2560x1440 · 2.8 mm · EXIR 2.0 30 m IR · human / vehicle detection · H.265+ · PoE · IP67 bullet
Indoor turret
DS-2CD1363G2-LIU(F)Essential Pro
6MP 3200x1800 · 2.8 mm · 30 m IR (dual-light model, IR mode) · human / vehicle detection · H.265+ · PoE · IP67 turret
Outdoor bullet
DS-2CD1063G2-LIU(F)Essential Pro
6MP 3200x1800 · 2.8 mm · 30 m IR (dual-light model, IR mode) · human / vehicle detection · H.265+ · PoE · IP67 bullet
Indoor turret
DS-2CD1383G0-IEssential Pro
8MP 4K 3840x2160 · 2.8 mm · EXIR 2.0 30 m IR · 120 dB WDR · H.265+ · PoE · IP67 turret
Outdoor bullet
DS-2CD1083G0-IEssential Pro
8MP 4K 3840x2160 · 2.8 mm · EXIR 2.0 30 m IR · 120 dB WDR · H.265+ · PoE · IP67 bullet
Indoor turret
DS-2CD1323G2-LIU(F)Interactive Pro
2MP · 2.8 mm · Smart Hybrid Light 30 m IR / white light (colour at night) · built-in mic · human / vehicle detection · H.265+ · PoE · IP67
Outdoor bullet
DS-2CD1023G2-LIU(F)Interactive Pro
2MP · 2.8 mm · Smart Hybrid Light 30 m IR / white light (colour at night) · built-in mic · human / vehicle detection · H.265+ · PoE · IP67
Indoor turret
DS-2CD1343G2-LIU(F)Interactive Pro
4MP · 2.8 mm · Smart Hybrid Light 30 m IR / white light (colour at night) · built-in mic · human / vehicle detection · H.265+ · PoE · IP67
Outdoor bullet
DS-2CD1043G2-LIU(F)Interactive Pro
4MP · 2.8 mm · Smart Hybrid Light 30 m IR / white light (colour at night) · built-in mic · human / vehicle detection · H.265+ · PoE · IP67
Indoor turret
DS-2CD1363G2-LIU(F)Interactive Pro
6MP · 2.8 mm · Smart Hybrid Light 30 m IR / white light (colour at night) · built-in mic · human / vehicle detection · H.265+ · PoE · IP67
Outdoor bullet
DS-2CD1063G2-LIU(F)Interactive Pro
6MP · 2.8 mm · Smart Hybrid Light 30 m IR / white light (colour at night) · built-in mic · human / vehicle detection · H.265+ · PoE · IP67
Indoor turret
DS-2CD1383G2-LIU(F)Interactive Pro
8MP · 2.8 mm · Smart Hybrid Light 30 m IR / white light (colour at night) · built-in mic · human / vehicle detection · H.265+ · PoE · IP67
Outdoor bullet
DS-2CD1083G2-LIU(F)Interactive Pro
8MP · 2.8 mm · Smart Hybrid Light 30 m IR / white light (colour at night) · built-in mic · human / vehicle detection · H.265+ · PoE · IP67
Indoor turret
DS-2CD1323G2-LIUF/SLProactive Pro
2MP · 2.8 mm · Smart Hybrid Light 30 m IR / white light · two-way talk (mic + speaker) · strobe light + siren · human / vehicle detection · PoE · IP67
Outdoor bullet
DS-2CD1023G2-LIUF/SLProactive Pro
2MP · 2.8 mm · Smart Hybrid Light 30 m IR / white light · two-way talk (mic + speaker) · strobe light + siren · human / vehicle detection · PoE · IP67
Indoor turret
DS-2CD1343G2-LIUF/SLProactive Pro
4MP · 2.8 mm · Smart Hybrid Light 30 m IR / white light · two-way talk (mic + speaker) · strobe light + siren · human / vehicle detection · PoE · IP67
Outdoor bullet
DS-2CD1043G2-LIUF/SLProactive Pro
4MP · 2.8 mm · Smart Hybrid Light 30 m IR / white light · two-way talk (mic + speaker) · strobe light + siren · human / vehicle detection · PoE · IP67
Indoor turret
DS-2CD1363G2-LIUF/SLProactive Pro
6MP · 2.8 mm · Smart Hybrid Light 30 m IR / white light · two-way talk (mic + speaker) · strobe light + siren · human / vehicle detection · PoE · IP67
Outdoor bullet
DS-2CD1063G2-LIUF/SLProactive Pro
6MP · 2.8 mm · Smart Hybrid Light 30 m IR / white light · two-way talk (mic + speaker) · strobe light + siren · human / vehicle detection · PoE · IP67
Indoor turret
DS-2CD1383G2-LIUF/SLProactive Pro
8MP · 2.8 mm · Smart Hybrid Light 30 m IR / white light · two-way talk (mic + speaker) · strobe light + siren · human / vehicle detection · PoE · IP67
Outdoor bullet
DS-2CD1083G2-LIUF/SLProactive Pro
8MP · 2.8 mm · Smart Hybrid Light 30 m IR / white light · two-way talk (mic + speaker) · strobe light + siren · human / vehicle detection · PoE · IP67
180° panoramic
DS-2CD2T46G2P-ISU/SLAdd-on
4MP 180° panoramic (dual sensor) · 40 m IR · two-way talk · strobe + siren · AcuSense human / vehicle · PoE · IP67
180° panoramic
DS-2CD2T66G2P-ISU/SLAdd-on
6MP 180° panoramic (dual sensor) · 40 m IR · two-way talk · strobe + siren · AcuSense human / vehicle · PoE · IP67
180° panoramic
DS-2CD2T83G2P-LISU/SLAdd-on
8MP 180° panoramic · Smart Hybrid Light 30 m · two-way talk · strobe + siren · human / vehicle · PoE · IP67
180° panoramic
DS-2CD1T832P-LIU/SLAdd-on
Exact regional SKU and specifications pending confirmation.
Version verification pendingAsk HJ about this model
180° panoramic
DS-2CD2387G2P-LSU/SLAdd-on
8MP 180° panoramic ColorVu turret · 24/7 colour · two-way talk · strobe + siren · AcuSense · PoE · IP67
360° fisheye
DS-2CD2955G0-IS(U)Add-on
5MP 360° fisheye · 8 m IR · dewarping views · ceiling / wall mount · PoE
360° fisheye
DS-2CD3956G2-IS(U)Add-on
5MP 360° AcuSense fisheye · 8 m IR · heat map · dewarping · PoE
360° fisheye
DS-2CD6365G1-IVSAdd-on
6MP 360° DeepinView fisheye · 15 m IR · two-way talk · people counting + heat map · IP67 IK10 · PoE
Complete the system
A camera is only one part of the installation. Compare the recorder, network and optional integration references below. Confirm the complete scope and exact regional devices before selection.
4-channel IP recorder
DS-7604NI-Q1(E)NVR / Recording
4 IP camera channels · H.265+ recording · local playback and HDMI output. Recorder capacity is not the installed camera count. Confirm the exact suffix, recording mode, storage and camera compatibility. Do not assume regional, Wi-Fi or built-in-PoE revisions are interchangeable.
8-channel IP recorder
DS-7608NI-Q1NVR / Recording
8 IP camera channels · H.265+ recording · local playback and HDMI output. Recorder capacity is not the installed camera count. Confirm the exact suffix, recording mode, storage and camera compatibility. Do not assume regional, Wi-Fi or built-in-PoE revisions are interchangeable.
16-channel IP recorder
DS-7616NI-Q2(D)NVR / Recording
16 IP camera channels · H.265+ recording · local playback and HDMI output. Recorder capacity is not the installed camera count. Confirm the exact suffix, recording mode, storage and camera compatibility. Do not assume regional, Wi-Fi or built-in-PoE revisions are interchangeable.
4-port PoE switch
DS-3E0105P-E/M(C)PoE / Networking
4 × 100 Mbps PoE ports and an uplink. Carries camera data and supplies compatible PoE devices. Confirm the actual revision and combined power budget, including any APs; port count alone is not a power allowance.
8-port PoE switch
DS-3E0109P-E/M(C)PoE / Networking
8 × 100 Mbps PoE ports and an uplink. Carries camera data and supplies compatible PoE devices. Confirm the actual revision and combined power budget, including any APs; port count alone is not a power allowance.
16-port PoE switch
DS-3E0318P-E/M(B)PoE / Networking
16 × 100 Mbps PoE ports with Gigabit RJ45 / SFP uplinks. Carries camera data and supplies compatible PoE devices. Confirm the actual revision and combined power budget, including any APs; port count alone is not a power allowance.
24-port PoE switch
DS-3E0326P-E/M(B)PoE / Networking
24 × 100 Mbps PoE ports with Gigabit RJ45 and SFP uplinks. Carries camera data and supplies compatible PoE devices. Confirm the actual revision and combined power budget, including any APs; port count alone is not a power allowance.
4-port Gigabit PoE switch
DS-3E0505P-E/MPoE / Networking
4 Gigabit PoE ports and a Gigabit uplink. Carries camera data and supplies compatible PoE devices. Confirm the actual revision and combined power budget, including any APs; port count alone is not a power allowance.
8-port Gigabit PoE switch
DS-3E0510P-E/MPoE / Networking
8 Gigabit PoE ports with Gigabit RJ45 / SFP uplinks. Carries camera data and supplies compatible PoE devices. Confirm the actual revision and combined power budget, including any APs; port count alone is not a power allowance.
16-port Gigabit PoE switch
DS-3E0518P-E/MPoE / Networking
16 Gigabit PoE ports and SFP uplinks. Carries camera data and supplies compatible PoE devices. Confirm the actual revision and combined power budget, including any APs; port count alone is not a power allowance.
24-port smart PoE switch
DS-3E1526P-EI/MPoE / Networking
24 Gigabit PoE ports with network management and topology tools. Carries camera data and supplies compatible PoE devices. Confirm the actual revision and combined power budget, including any APs; port count alone is not a power allowance.
Optional ceiling Wi-Fi AP
DS-3WAP622E-SIOptional Wi-Fi / Site Network
Wi-Fi 6 ceiling AP with a 2.5 Gigabit PoE input. A site-network option, not a mandatory CCTV component. Coverage, VLANs, mounting and power are confirmed separately; no fixed user-capacity promise is made.
Optional in-wall Wi-Fi AP
DS-3WAP621E-SIOptional Wi-Fi / Site Network
In-wall Wi-Fi 6 AP reference with PoE input. A site-network option, not a mandatory CCTV component. Coverage, VLANs, mounting and power are confirmed separately; no fixed user-capacity promise is made.
Optional ceiling Wi-Fi AP
DS-3WAP622G-SIOptional Wi-Fi / Site Network
Wi-Fi 6 ceiling AP reference with a Gigabit PoE uplink. A site-network option, not a mandatory CCTV component. Coverage, VLANs, mounting and power are confirmed separately; no fixed user-capacity promise is made.
AX HYBRID PRO integration reference
DS-PHA64-Kit-WB(B)Alarm / Integration
Alarm-panel, keypad and separate siren-box reference for Proactive Defence. Manufacturer kit contents are not the HJ installed scope: the supplied HJ plan excludes PIR and door-contact detectors. Match the regional version and configure and demonstrate the camera-event-to-alarm workflow.
No matching model. Try a shorter model code or a function.
180° frontage or 360° overview?
180° panoramic
Use a stitched wide view to plan a frontage, porch or compound side. Confirm the identification distance rather than assuming one overview captures every detail.
360° fisheye
Consider a ceiling overview for a shop, office or hall. Confirm the mounting position and supported dewarped views on the chosen recorder and app.
Capacity check
Each added camera needs compatible recording capacity and power. Review channel count, PoE ports, power budget and storage before expanding the system.
Plan the whole installation
Start with the viewing requirement, then confirm the complete installation.
Coverage
Entrances, viewing distance and lighting.
Recording
Recorder capacity, storage and remote access.
Handover
Settings, live tests and user training.
Before you choose
Does Interactive Pro include two-way talk?
The supplied Interactive Pro selections have a built-in microphone. Do not treat that as two-way talk. The Proactive Pro selections explicitly add microphone and speaker, with strobe and siren.
What does Pro mean here?
Pro identifies this IP camera / NVR plan family. It is not a promise that every listed component belongs to a manufacturer Pro product range.
Can panoramic cameras be added?
The plan includes 180-degree panoramic and 360-degree fisheye options. Check coverage, dewarping support, recorder channels, PoE ports and power budget before adding a camera. A wide overview does not replace a close identification view.
Are all listed versions interchangeable?
No. Lens, memory-card option, firmware and suffix matter. The source includes one panoramic reference without a matched global manufacturer page; its specifications remain pending until the exact local SKU is confirmed.
